IBM Aptiva 2144 User Manual

Table 5-6 (Page 2 of 3). VESA Local Bus Riser Connector
Description Pin Pin Description
CD(14) B10 A10 Ground
CD(16) B11 A11 CD(17)
CD(18) B12 A12 VCC
CD(20) B13 A13 CD(19)
Ground B14 A14 CD(21)
CD(22) B15 A15 CD(23)
CD(24) B16 A16 CD(25)
CD(26) B17 A17 Ground
CD(28) B18 A18 CD(27)
CD(30) B19 A19 CD(29)
VCC B20 A20 CD(31)
CA(31) B21 A21 CA(30)
Ground B22 A22 CA(28)
CA(29) B23 A23 CA(26)
CA(27) B24 A24 Ground
CA(25) B25 A25 CA(24)
CA(23) B26 A26 CA(22)
CA(21) B27 A27 VCC
CA(19) B28 A28 CA(20)
Ground B29 A29 CA(18)
CA(17) B30 A30 CA(16)
CA(15) B31 A31 CA(14)
VCC B32 A32 CA(12)
CA(13) B33 A33 CA(10)
CA(11) B34 A34 CA(8)
CA(9) B35 A35 Ground
CA(7) B36 A36 CA(6)
CA(5) B37 A37 CA(4)
Ground B38 A38 HITM
CA(3) B39 A39 BE 0
CA(2) B40 A40 VCC
No Connection B41 A41 BE 1
LRESET B42 A42 BE 2
D/ C B43 A43 Ground
M/ IO B44 A44 BE 3
Parts/Test Point Locations 5-29

IBM Aptiva 2144 Specifications

General

Brand	IBM
Model	Aptiva 2144
Category	Desktop
Language	English
