IBM Aptiva 2144 User Manual

Pin Signal Name I/O Pin Signal Name I/O
35 DP0 I 54 SIMMD10 I/O
36 DP0 I 55 SIMMD11 I/O
37 DP1 I 56 SIMMD11 I/O
38 DP1 I 57 SIMMD12 I/O
39 Ground I 58 SIMMD12 I/O
40 BCAS0 I 59 +5 V dc I
41 BCAS2 I 60 SIMMD13 I/O
42 BCAS3 I 61 SIMMD13 I/O
43 BCAS1 I 62 SIMMD14 I/O
44 RAS4 I 63 SIMMD14 I/O
45 RAS5 I 64 SIMMD15 I/O
46 BS1 I 65 SIMMD15 I/O
47 AWE I 66 BS2 I
48 Open 67 PD1 O
49 SIMMD8 I/O 68 PD2 O
50 SIMMD8 I/O 69 PD3 O
51 SIMMD9 I/O 70 PD4 I
52 SIMMD9 I/O 71 BS3 I
53 SIMMD10 I/O 72 Ground
Parts/Test Point Locations 5-31
