Page #207 background image
Asm– Part
Index Number Units Description
2–1 System Board
Note:
See theAppendix, “Model/Monitor
Configurations and FRU Part
Numbers” on page A-1 for model
specifications.
All system board FRUs are shipped
without processor, cache memory
modules, video DRAM modules, or
SIMMs. When upgrading or replacing
a system board, any non-failing FRUs
must be removed from the original
system board and reinstalled on the
new FRU system board.
–1 40H4250 1 System Board - Type I-1
–2 71G0794 1 486DX2-50MHz Processor
–2 71G0795 1 486DX2-66MHz Processor
–2 41H7822 1 486DX2-80MHz Processor
–2 42H0380 1 486DX4-100MHz Processor
–2 07H0972 1 Cx586C-100MHz Processor
–1 11H9669 1 System Board - Type I-2
–2 06H7589 1 P54-75MHz Processor
–2 06H6063 1 P54C-100MHz Processor
–2 42H0378 1 P54C-120MHz Processor
–2 06H8228 1 P54C-133MHz Processor
–2 06H9892 1 P54C-150MHz Processor
–2 07H0971 1 P54C-166MHz Processor
–NS 06H5729 1 Processor Fan
–3 06H7225 1 Riser Card (ISA/PCI)
–3 10H2830 1 Riser Card (4-Connector AT)
–4 93F2394 1 Hard Disk Drive Ribbon Cable
–5 93F2395 1 Diskette Drive Ribbon Cable
–6 93F2388 1 Indicator LED and Cable, Hard Drive
–7 93F2389 1 Indicator LED and Cable, Power
–NS 13H8078 1 Dual LED Indicator Cable
06H5743 1 Hard Disk/CD-ROM Bracket
Parts Catalog 7-5
