Appendix D. Installing removable media devices in the 5065
Expansion Unit
You may install removable media device features into the 5065 or 5066 Expansion
Unit yourself. It takes approximately 1 hour to install the hardware. However, if
you elect not to install the feature, contact IBM or an authorized dealer to install
the removable media device feature for a fee.
Allow additional time to complete your jobs, to back up your system, and to IPL
your system, and verify your hardware configuration.
When you use these instructions, you will do the following:
v Remove the front cover for the expansion unit.
v Install your new hardware.
v Install the cover.
v IPL your operating system.
v Verify your new hardware configuration.
Note: Your 5066 Expansion Unit consists of two independent 5065 Expansion
Units. The installation instructions for each expansion unit in your 5066 are
identical.
Before you begin:
v Ensure that you have a current backup of your operating system and licensed
programs. If you have backed up the operating system and licensed programs
since the last time you applied PTFs, that backup is acceptable.
v Ensure that you take a few minutes to become familiar with these instructions.
v If there are incorrect, missing, or visibly damaged parts, contact one of the
following:
– Your authorized dealer
– IBM Rochester Manufacturing Automated Information Line (R-MAIL)
- 1-800-300-8751 (United States)
- 1-507-253-5242 (worldwide)
Table 5. Possible removable media device configurations
Removable Media Device Possible Installation Configurations
(double for 5066)
CD-ROM Drive (4425) One per 5065
4 GB Tape Drive (4482) Install up to 2
12 GB Tape Drive (4483) Install up to 2
25 GB Tape Drive (4486) Install up to 2
© Copyright IBM Corp. 1999, 2000 55
