c. When you unroll the wrist strap, remove the liner from the copper foil at
the end.
d. Attach the copper foil to an exposed, unpainted metal surface on the
frame of the 5065 expansion unit (electrical ground).
__ 5. Be sure you understand the complexity of the steps in “Concurrent
procedure (system-unit powered on)” before you begin. If you do not feel
comfortable using the concurrent procedure, go to “NonConcurrent
procedure (system-unit powered off)” on page 61.
Concurrent procedure (system-unit powered on)
Before you perform a concurrent install, you first need to find out the Direct Select
Address for the removable media you are installing. Read “Finding the Direct
Select Address” to find out how to find the disk unit Direct Select Address. Once
you know the Direct Select Address, go to “Performing the concurrent install” on
page 59 to complete the install.
Finding the Direct Select Address
Follow these steps to find the Direct Select Address for your new removable media
device.
__ 1. Refer to the label on the inside of the front cover for the location of your
new removable media device.
__ 2. Look at Table 6 to find the Direct Select Address for the location of your
new removable media device.
Table 6. Removable media Direct Select Address
Location Direct Select Address/Unit Address
D41 0X10 0007 00FF
D42 0X10 0006 00FF
__ 3. The value for X in the Direct Select Address is different for each system. To
determine the value for X perform the following steps:
a. If you have not already done so, print the System Configuration List:
1) On an AS/400 command line, type:
STRSST
Press the Enter key.
2) When the Start a Service Tools menu appears, select the Start a
service tool option.
Press the Enter key.
3) When the Start a Service Tool menu appears, select the Hardware
service manager option.
Press the Enter key.
4) When the Hardware Service Manager menu appears, select the
Packaging hardware resources (system, frames, cards...) option.
Press the Enter key.
5) When Confirm Remove of Packaging Hardware Resources(s) appears,
press F6 to the configuration list. Place the configuration list in this
book.
6) To return to the Main menu, press F3 three times and then press the
Enter key.
b. On the System Configuration List, locate your expansion unit.
58 Setting Up Your 5065 or 5066 Expansion Unit V4R5
