the following figure.
Handle
Retaining Clip
Bottom of Tailstock
Cassette Linkage Assembly
b. Rotate the adapter so that the adapter engages the slot in the bottom retaining
clip and the top corner of the adapter is seated into the adjustable adapter top
retaining clip.
Note: If the adapter is not a full height adapter, you must slide the adjustable
top left adapter retaining clip downward until the lower edge of the
