Specifications
This section contains system specifications for both the 7311 Model D10 I/O
Subsystem, and the 7311 Model D20 I/O Subsystem
Model D10 Specifications
Dimensions 7311-D10 Two 7311-D10s with
Enclosure
Height 170 mm (6.6 in) 178 mm (7.0 in)
Width 220 mm (8.7 in) 445 mm (17.5 in)
Depth 711 mm (28.0 in) 711 mm (28.0 in)
Weight 16.8 kg (37 lbs) 39.1 kg (86 lbs)
Electrical
Power source loading for two 7311-D10 (max.) 0.21 kVA
Voltage range 200 to 240 V ac, (dc not supported)
Frequency 50 or 60 Hz
Thermal output (typical) 461 Btu/hr
Thermal output (max.) 683 Btu/hr
Power requirements (typical) 135 watts
Power requirements for two 7311-D10 (max.) 200 watts
Power factor 0.91
Inrush current² 64 amps
Maximum altitude
3, 4
3048 m (10000 ft.)
Temperature Requirements³ Operating
10 to 38°C
50 to 100°F)
Non-Operating
1 to 60°C
(34 to 140°F)
Storage
1 to 60°C
(34 to 140°F)
Humidity Requirements⁴ Operating Non-Operating Storage
(Noncondensing) 8 to 80% 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (81°F) 29°C (84°F)
Noise Emissions
1, 4
Operating Idle
L
WAd
, one 7311-D10
L
WAd
, two 7311-D10
L
WAd
, four 7311-D10
5.6 bels
5.9 bels
6.2 bels
5.6 bels
5.9 bels
6.2 bels
<L
pA
>
m
, one 7311-D10
<L
pA
>
m
, two 7311-D10
<L
pA
>
m
, four 7311-D10
40 dBA
43 dBA
46 dBA
40 dBA
43 dBA
46 dBA
Install/Air Flow: Maintaining service clearance allows proper air flow.
Service Clearances See 7014 Model T00 and T42 Rack for T00 or T42 rack
service clearances.
1. See page 202 for definitions of noise emissions positions. See noise emissions note 4.
2. Inrush currents occur only at initial application of power, no inrush occurs during normal
power off-on cycle.
3. The upper limit of the dry bulb temperature must be derated 1°C per 137 m (450 ft.) above
915 m (3000 ft.).
4. The upper limit of the wet bulb temperature must be derated 1°C per 274 m (900 ft. ) above
305 m (1000 ft.).
Chapter 1. Reference Information
37
