2) The metal shield has clips that slide over the top of the tailstock. Ensure
that these clips are holding the EMC bracket to the tailstock.
Top of Tailstock
p. Press the lock on the handle and rotate the adapter handle until the handle is
in the down position (adapter or blank filler moves up into the cassette
assembly).
Handle
q. Using your system documentation, determine if the adapter you are installing is
hot-swappable or not. If the adapter is hot-swappable, move the slider on the
118 Eserver pSeries 7311 Model D10 and Model D20 Service Guide
