Part number Units per assembly Description
11P4861 1 Blank cassette
11P3990 1 Door key
44P0182 1 DASD service tool
11P4914 1 MCM/L3/Pass-through plug location
map (tri-fold chart): should be
installed in the primary rack.
11P4055 N/A Plug count adhesive replacement
label
44P209 1 Test card assembly MCM/L3
short-to-GND
00P7023
36P2435
36P2436
36P2437
N/A
N/A
Vacuum cleaner (110 Vac)
Vacuum cleaner (220 Vac)
Omega Filter 0.3 Micron
Cord Omega UK Plug
07H6824 12 Bracket, insert
07H6823 2 Bracket, 11 x 6 insert
11P1262 4 Bracket, assembly with foam
07H6827 4 Blank filler plate - 3
07H2826 3 Blank filler plate - 1
54G2882 16 Screws
31L7174 1 Velcro (roll)
08J5557 1 Wheel chocks
44P0144 Tailgate assembly
09P2481 Rack lift tool
11P4369 Lift place assembly tool
Models 870 and 890 - Shorts test qualified service meters and fail criteria: For use by authorized
service providers.
Use the table below to help you choose a meter to use when performing the MCM or L3 shorts test.
Table 1. Shorts test qualified service meters and fail criteria
Manufacturer Model Range (ohm)
Accuracy at 1.0 ohm
or less Fail criteria (ohm)
Fluke 8060A 200 +/-0.04 +0.40
Fluke 8060A/AA 200 +/-0.04 +0.40
Fluke 8062A 200 +/-0.04 +0.40
Fluke 187 500 +/-0.10 +0.40
Fluke 189 500 +/-0.10 +0.40
Fluke 83 (original models) 400 +/-0.10 +0.40
Fluke 85 (original models) 400 +/-0.10 +0.40
Fluke 87 (original models) 400 +/-0.10 +0.40
Fluke 87-4 500 +/-0.10 +0.40
Fluke 89-4 500 +/-0.10 +0.40
