IBM iSeries 800 - Locations - FC 5074 Expansion I;O Tower

Possible failing
component
FRU name Position Type or CCIN
number (see the
Type, model, and
part number list)
Remove and
replace
procedure
Additional
comments
Integrated xSeries
Server
PCI card C05, C11 2890 (See page
527) or 2892 (See
page 527)
Go to FC
8094-001 (lower
half), FC 9094 -
Cards (dedicated)
If IXS is in C05,
C06 is empty.If
the IXS is 2890,
only a short cad
can be used in
C07.
If the IXS is in
C11, C12 must be
empty.
If the IXS is an
FC 2890, only a
short card can be
used in C13.
Disk unit Disk unit D01 through D40,
D46 through D50
See the Type,
model, and part
number list
Go to Recovery
procedures
Optical device Optical device D41 See the Type,
model, and part
number list
Go to FC 5094,
FC 9094 -
Removable media
- D41 and D42
Tape unit Tape unit D42 See the Type,
model, and part
number list
Go to FC 5094,
FC 9094 -
Removable media
- D41 and D42
Control panel Control panel NB1 247A (See page
523)
Go to Models 870
and 890 (FC
9094) - Control
panel - NB1
Device board Device board DB1, DB2 283D (See page
526) or 28CC
(See page 528)
Go to FC 5094,
FC 9094 - Device
board - DB1, DB2
Device board Device board DB3 283C (See page
526) or 28CB
(See page 528)
Go to FC 5094,
FC 9094 - Device
board - DB3
v SPCN card
v Service
processor
v Tower card
v Multi-adapter
bridge (All)
Tower card CB1 28B6 (See page
528)
Go to FC 5094,
FC 9094 - Tower
card - CB1
Time of day
battery
Time of day
battery
On tower card
CB1
See the Type,
model, and part
number list.
Go to FC 9094 -
Time of day
(TOD) battery
Locations — FC 5074 Expansion I/O Tower
