Final assembly - Models 270, 800, and 810 System Unit Expansion
Cover assembly - Models 270, 800, and 810: For use by authorized service providers.
Figure 1. Cover assembly - Models 270, 800, and 810
Table 1. Cover assembly - Models 270, 800, and 810
Index Part number Units Description
1 24L1652 1 Cover, rear (Model 270
only)
2 24L1630 1 Cover, top
3 75G2878 2 Screw, M3.5 x 8mm
4 24L1632 1 Cover, side
5 75G2878 2 Screw, M3.5 x 8mm
Analyze hardware problems 367
