Possible failing
component FRU name Position
Type or CCIN
number (see the
Type, model, and
part number list)
Remove and
replace
procedure
Additional
comments
v Card enclosure
or backplane
v Clock card
v SPCN card
v HSL I/O bridge
v Processor
regulator
v Memory riser
card
v System unit
backplane
v HSL ring
connection
v HSL controller
v Processor
v Service
processor
v IOP
v Multi-adapter
bridge (all)
System unit
backplane
MB1 25B9 (See page
523) (Note:
Embedded IOP
(type 286C) is
exchanged with
the system unit
backplane.)
25BA (See page
523) (Note:
Embedded IOP
(type 286D) is
exchanged with
the system unit
backplane.)
25F0 (See page
524) (Note:
Embedded IOP
(type 286E) is
exchanged with
the system unit
backplane.)
Go to Models
270, 800, and 810
- System unit
backplane - MB1
Memory card Memory card A through H on
the system
backplane
3092 (See page
529), 3093 (See
page 529), 3094
(See page 529),
3096 (See page
529)
Go to Models
270, 800, and 810
- Memory - A
through H
IOP PCI cards C03 - C06 2842 (See page
527), 2843 (See
page 527), or
2844 (See page
527)
Go to Models
270, 800, and 810
- Cards
(dedicated)
IOA PCI cards C01 through C07 See the Type,
model, and part
number list
Go to Models
270, 800, and 810
- Cards
(dedicated)
If 2890 IXS in
C04, only a short
card can be in
C03.
Integrated xSeries
Server
PCI card C04 2890 (See page
527) or 2892 (See
page 527)
Go to Models
270, 800, and 810
- Cards
(dedicated)
IF IXS in C04,
only a short card
can be in C03.
Disk unit Disk unit D01 through D06 See the Type,
model, and part
number list
Go to Models
270, 800, and 810
- Disk unit
(dedicated)
Optical device Optical device D07 See the Type,
model, and part
number list
Go to Models
270, 800, and 810
- Removable
media - D07 and
D08
246 Hardware (Remove and Replace; Part Locations and Listings)
