Possible failing
component FRU name Position
Type or CCIN
number (see the
Type, model, and
part number list)
Remove and
replace
procedure
Additional
comments
Integrated
xSeries
(TM)
Server (IXS)
PCI card C05, C11 2890 (See page
527)
Go to FC 5074,
FC 5079, FC
5094, FC 5294 -
Cards
(dedicated).
If IXS in C05, C06
is empty - if 2890
IXS, only a short
card can be in
C07.
If IXS in C11, C12
is empty - if 2890
IXS, only a short
card can be in
C13
v High-speed link
I/O adapter
v PCI host bridge
adapter
HSL I/O bridge
card
C08 2691 (See page
524), 2739 (See
page 524)
Go to FC 5074,
FC 5079, FC
5094, FC 5294 -
Cards
(dedicated).
AMD AMD B01, B02 See Final
assembly — FC
5074, FC 5094
Go to FC
5074/5079, FC
9074, FC 9079 -
AMD - B01 and
B02.
Power board Power board PB1 See Final
assembly - FC
5074, FC 5094
Go to FC 5074,
FC 5079, FC
9079 - Power
distribution board
- PB1
AC module /
charger
AC input / charger A01 See Final
assembly - FC
5074, FC 5094
Go to FC 5074,
FC 5079, FC
9079 (with single
line cord) - AC
charger - A01.
AC module AC module A01 See Final
assembly - FC
5074, FC 5094
Go to FC 5074,
FC 5079, FC
9079 (with dual
line cord) - AC
charger - A01.
AC module AC module A02 See Final
assembly - FC
5074, FC 5094
Go to FC 5074,
FC 5079, FC
9079 (with dual
line cord) - AC
charger - A01.
Power supply Power supply P01, P02, P03 See Final
assembly - FC
5074, FC 5094
Go to FC 9074,
FC 9079, FC
5074/5079 -
Power supply -
P01, P02, and
P03.
Battery Battery T01 through T04 See the Type,
model, and part
number list
Go to FC 5074,
FC 5079, FC
9079 - Batteries -
T01, T02, T03,
and T04.
Analyze hardware problems 297
