Position
Possible
failing item DSA (BBBBCcbb) Unit address
C07 IXS attached
IOA
yyyy-10-00 E003FFFF
C09 IOP yyyy-14-00 FFFFFFFF
C09 Storage IOA yyyy-10-00 4FFFFFFF
C09 Comm/Wkst
IOA
yyyy-10-00 E4FFFFFF
C09 IXS attached
IOA
yyyy-10-00 E004FFFF
C10 Storage IOA The IOA has the same DSA as the first
IOP found in the following list: C09, C07,
C05.
6FFFFFFF
C10 Comm/Wkst
IOA
The IOA has the same DSA as the first
IOP found in the following list: C09, C07,
C05.
E6FFFFFF
C10 IXS attached
IOA
The IOA has the same DSA as the first
IOP found in the following list: C09, C07,
C05.
E006FFFF
C11 (IXS capable
position)
IOP yyyy-20-00 FFFFFFFF
C12 (empty if IXS
in C11)
Storage IOA yyyy-20-00 2FFFFFFF
C12 (empty if IXS
in C11)
Comm/Wkst
IOA
yyyy-20-00 E2FFFFFF
C13 IOP yyyy-23-00 FFFFFFFF
C13 Storage IOA yyyy-20-00 3FFFFFFF
C13 Comm/Wkst
IOA
yyyy-20-00 E3FFFFFF
C13 IXS attached
IOA
yyyy-20-00 E003FFFF
C14 IOP yyyy-24-00 FFFFFFFF
C14 Storage IOA yyyy-20-00 4FFFFFFF
C14 Comm/Wkst
IOA
yyyy-20-00 E4FFFFFF
C14 IXS attached
IOA
yyyy-20-00 E004FFFF
C15 Storage IOA The IOA has the same DSA as the first
IOP found in the following list: C14, C13,
C11.
6FFFFFFF
C15 Comm/Wkst
IOA
The IOA has the same DSA as the first
IOP found in the following list: C14, C13,
C11.
E6FFFFFF
C15 IXS attached
IOA
The IOA has the same DSA as the first
IOP found in the following list: C14, C13,
C11.
E006FFFF
D01 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″L-1″.
x00300FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
346 Hardware (Remove and Replace; Part Locations and Listings)
