Index Part number Units Description
2 28L0657 2 Screw, M3.5 x 8mm
3 21P7341 1 Cover, top
4 75G2878 2 Screw, M3.5 x 8mm
5 21P7342 1 Slide-out cover (MB1)
6 21P7360 1 Cover, rear
7 21P7343 1 Cover, right side
8 75G2878 2 Thumbscrew
9 21P7350 1 Cover front (double-wide iSeries)
Final assembly - Model 825: For use by authorized service providers.
Figure 1. Final assembly - Model 825
Table 1. Final assembly - Model 825
Analyze hardware problems 387
