Index Part number Units Description
22 21P7324 AR Filler, RIO-G containment
23 75G2878 2 Screw
24 21P7332 1 Bracket, Ethernet
25 75G2878 6 Screw
26 21P7112 1 Bracket (busbar)
27 75G2878 2 Screw
28 NONUM 1 Backplane assembly (see
the Type, model, and part
number list)
28 21P7312 1 Stiffener
29 86G7603 3 Screw, voltage
30 11H3846 2 Screw, ground
31 75G2878 11 Screw, backplane mounting
32 21P7298 1 Insulator
Part assemblies - Models 830/SB2: For use by authorized service providers.
Control panel assembly (with FC 9074)
Cover assembly (with FC 9074)
Final assembly (front) (with FC 9074)
Final assembly (rear) (with FC 9074)
Cover assembly - Models 830 and SB2 with FC 9074: For use by authorized service providers.
Figure 1. Cover assembly - Models 830 and SB2 with FC 9074
