Index Part number Units Description
11 NONUM 1 Removable media cage
assembly
12 1621811 2 Screw, M4 (10mm)
13 1621817 2 Screw
14 24L1067 1 Keystick EMC plate
15 1621811 2 Screw, M4 (10mm)
16 NONUM AR 5 Disk unit cage assembly
(slots D01 through D50)
17 1621811 12 Screw, M4 (10mm)
18 1621817 6 Screw
19 AR Disk unit assembly. See the
Type, model, and part
number list.
Figure 4. Final Assembly, Front - Models 830 and SB2 with FC 9074 (continued)
Analyze hardware problems 399
