Table 1. Final assembly, front - Models 840 and SB3 Processor Tower
Index Part number Units Description
1 23L3367 1 EMC access plate, front cage
2 1621811 3 Screw, M4 (10mm)
3 23L3365 1 EMC access plate, front cage
4 1621811 3 Screw, M4 (10mm)
5 23L3428 1 EMC bracket, top
6 1621811 6 Screw, M4 (10mm)
7 23L3433 1 EMC bracket, right
8 1621811 15 Screw, M4 (10mm)
9 NONUM 1 Front cage/backplane Asm. See Final assembly, rear - Models 840 and SB3
Processor Tower (See page 418).
10 1621811 12 Screw, M4 (10mm)
11 23L3466 1 Control panel assembly, processor tower. See “Control panel assembly,
processor tower - Models 840 and SB3” on page 419.
412 Hardware (Remove and Replace; Part Locations and Listings)
