Table 3. Final assembly - FC 9079 Base I/O Tower (Models 840 and SB3), (continued)
Index Part number Units Description
14 NONUM 1 Shelf, base disk unit
15 1621811 3 Screw, M4 (10mm)
16 24L0892 1 Base disk unit board/stiffener assembly (DB3)
17 24L1029 AR Disk unit board/stiffener assembly (DB1 and DB2)
18 1621838 1 Screw
19 NONUM AR Shelf, disk unit
Analyze hardware problems 425
