Index Part number Units Description
53 53P4651 1 Power sub frame assembly
54 1621811 12 Screw, M4 (10mm)
55 97H7318 1 Battery pack - This part
number includes four
batteries. Refer to the
BATRY symbolic FRU for
additional information.
56 1621811 12 Screw, M4 (10mm)
57 24L0940 AR Filler, spacer
58 1621811 2 Screw, M4 (10mm)
59 NONUM 1 EMC access plate
60 1621811 2 Screw, M4 (10mm)
61 24L0939 AR Filler, power supply
62 1621811 2 Screw, M4 (10mm)
63 44H8641 2 Cable clamp, top
64 44H8640 2 Cable clamp, base
65 1621811 2 Screw, M4 (10mm)
66 97H7316 1 Battery charger
67 1621811 4 Screw, M4 (10mm)
68 90H6629 3 Power supply — 765 watts
(P01, P02, P03)
Part assemblies - Models 870 and 890 (FC 9094 Base I/O Tower): For use by authorized service
providers.
Bulk power enclosure assembly - Models 870 and 890
Control panel - FC 9094 Base I/O Tower
Cover assembly - FC 9094 Base I/O Tower
Cover assembly - Models 870 and 890 Processor Tower
Final assembly - FC 9094 Base I/O Tower
Final assembly - Models 870 and 890
Processor subsystem assembly - Models 870 and 890
Bulk power enclosure assembly - Models 870 and 890: For use by authorized service providers.
Figure 1. Bulk power enclosure assembly - Models 870 and 890
Analyze hardware problems 429
