Table 3. Final assembly (front) - FC 9094 Base I/O Tower, (continued)
Index Part number Units Description
14 NONUM 1 Shelf, base disk unit
15 1621811 3 Screw, M4 (10mm)
16 53P4001 1 Base disk unit board/stiffener assembly (DB3)
17 53P4002 AR Disk unit board/stiffener assembly (DB1 and DB2)
18 1621838 1 Screw
19 NONUM AR Shelf, disk unit
438 Hardware (Remove and Replace; Part Locations and Listings)
