Table 1. Final assembly - Models 870 and 890
Note: For more details, follow the links given below.
Index Part number Units Description
1 NONUM 2 Bulk power enclosure, see
Bulk power enclosure
assembly - Models 870 and
890
2 NONUM 4 Screw, (BPE mounting)
3 44P1124 1 Unit emergency power off
(UEPO) switch. See the
Models 870 and 890 - Unit
Emergency Power Off
(UEPO) card remove and
replace procedure.
4 2665528 2 Screw
5 NONUM 1 CEC assembly, see
Processor subsystem
assembly - Models 870 and
890
6 NONUM 4 Screw, (CEC mounting)
Processor subsystem assembly - Models 870 and 890: For use by authorized service providers.
Figure 1. Processor subsystem assembly, front - Models 870 and 890
442 Hardware (Remove and Replace; Part Locations and Listings)
