Index Part number Units Description
10 41L5448 2 Air moving device (Fans) (B01 and B02)
11 21P4894 1 Chassis
12 1621811 6 Screw, M4 (10mm)
13 00P2382 1 Power distribution (PB1)
14 00G1268 6 Screws, M4X
15 44K0243 1 Cable tray
16 41L5206 1 Cover
17 00G1268 2 Screw, M4X
18 04N6797 AR FC 5078, FC 0578 PCI node board assembly (CB1)
18 53P2354 AR FC 5088, FC 0588 PCI node board assembly (CB1)
19 00G1268 6 Screw, M4X
20 04N4498 1 Mounting bracket
21 1621811 2 Screw, M4 (10mm)
NA 04N3038 AR Power supply to PDU line cord
NA 21P6094 AR Miscellaneous power cable
NA 41L5650 AR SPCN cable
NA 41L5649 AR Display panel cable
NA 41L5652 AR Fan control cable
Part assemblies - FC 5095, FC 0595: For use by authorized service providers.
Cover assembly - FC 5095
Final assembly - FC 5095
Final assembly - FC 0595 rack mounted expansion unit
Cover assembly - FC 5095 Expansion I/O Tower: For use by authorized service providers.
Figure 1. Cover assembly - FC 5095 Expansion I/O Tower
470 Hardware (Remove and Replace; Part Locations and Listings)
