Name Description Part number
PWR60 Power distribution board (PB1) to Device board 3 (DB3) 24L1886
PWR61 to PWR64 Power distribution board (PB1) to Device board 2 (DB2) 97H7483
PWR65 Power distribution board (PB1) to Device board 2 (DB2) 97H7544
PWR66 to PWR69 Power distribution board (PB1) to Device board 2 (DB2) 97H7543
PWR70 Power distribution board (PB1) to Device board 1 (DB1) 97H7544
PWR71 to PWR74 Power distribution board (PB1) to Device board 1 (DB1) 97H7543
PWR75 Power distribution board (PB1) to AMDs (B01 and B02) 97H7475
PWR77 AC Input (A01) to Power supply 1 (P01 and P03) 04N2181
PWR78 AC Input (A02) to Power supply 2 (P00 and P02) 04N2181
PWRC80 Power distribution board (PB1) to CEC interface 97H7479
PWRC81 AC Input (A01) to Processor power (PP1) 04N6134
PWRC82 AC Input (A02) to Processor power (PP2) 04N6134
Table 18. Models 830, SB2 System Unit with FC 9074 - Signal cables - dual line cord
Name Description Part number
SIG60 IOA in tower card (CB1) to Device
board 3 (DB3)
97H7481
SIG61 IOA in tower card (CB1) to Device
board 2 (DB2)
44L0070
SIG62 IOA in tower card (CB1) to Device
board 1 (DB1)
97H7484
SIG63 Control panel (NB1) to Device board
3 (DB3)
24L1752
SIG64 Tower card (CB1) to Power
distribution board (PB1 - includes P/N
97H7476, 97H7477, 97H7607) (part
of the Tower card FRU assembly)
24L0843
SIGC65 Control panel (NB1) to CEC interface 97H7327
SIGC66 CEC interface to CEC backplane
interface, to Power supplies (PP1 and
PP2), and to AMD (BP1 and BP2)
04N3037
SIGC67 CEC cage assembly to CEC
bulkhead
97H7472
SIGC68 Part of backplane FRU assembly
(MB1) (internal cable)
97H7601
SIGC69 Part of backplane FRU assembly
(MB1) (internal cable)
97H7603
SIGC70 Part of backplane FRU assembly
(MB1) (internal cable)
97H7600
SIGC71 JTAG-A (external cable) Tower card
(CB1) to CEC cage assembly.
97H7486 (6 meter)
21H7375 (3 meter)
SIGC72 V/S COMM (external cable) Tower
card (CB1) to CEC cage assembly.
44L0033
SIGC73 HSL (C08) to backplane FRU
assembly MB1 cable
97H7326
Analyze hardware problems 497
