Name Description Part number
PWR61 to PWR64 Power distribution board (PB1) to Device board 3 (DB3) 97H7483
PWR65 Power distribution board (PB1) to Device board 2 (DB2) 97H7544
PWR66 to PWR69 Power distribution board (PB1) to Device board 2 (DB2) 97H7543
PWR70 Power distribution board (PB1) to Device board 1 (DB1) 97H7544
PWR71 to PWR74 Power distribution board (PB1) to Device board 1 (DB1) 97H7543
PWR75 Power distribution board (PB1) to AMDs (B01 and B02) 97H7475
PWR77 AC input (A01) to Power supply 1 (P01 and P03) 04N2181
PWR78 AC input (A02) to Power supply 2 (P00 and P02) 04N2181
Table 32. FC 5074, FC 5079, FC 5094, FC 9094 Expansion I/O Tower - Signal cables - dual Line Cord
Name Description Part number
SIG60 IOA in tower card (CB1) to Device
board 3 (DB3)
97H7481
SIG61 IOA in tower card (CB1) to Device
board 2 (DB2)
44L0070
SIG62 IOA in tower card (CB1) to Device
board 1 (DB1)
97H7484
SIG63 Control panel (NB1) to Device board
3 (DB3)
24L1752
SIG64 Tower card (CB1) to Power
distribution board (PB1 - includes P/N
97H7476, 97H7477, 97H7607) (Part
of Tower card FRU assembly)
24L0843
FC 5075 Expansion I/O Tower: Figure 19. FC 5075 Expansion I/O Tower power and signal cables
Analyze hardware problems 515
