IBM PowerPC 750GX User Manual

User’s Manual
IBM PowerPC 750GX and 750GL RISC Microprocessor
Signal Descriptions
Page 256 of 377
gx_07.fm.(1.2)
March 27, 2006
7.2.4.1 Transfer Type (TT[0–4])
The transfer type (TT[0–4]) signals consist of five input/output signals on the 750GX. For a complete descrip-
tion of TT[0–4] signals and for transfer type encodings, see Table 7-1.
Transfer Type (TT[0–4])—Output
Transfer Type (TT[0–4])—Input
Table 7-1 describes the transfer encodings for the 750GX bus master.
State Asserted/
Negated
Indicates the type of transfer in progress.
Timing Assertion/
Negation/
High
Impedance
The same as A[0–31].
State Asserted/
Negated
Indicates the type of transfer in progress (see Table 7-1).
Timing Assertion/
Negation
The same as A[0–31].
Table 7-1. Transfer Type Encodings for PowerPC 750GX Bus Master
(Page 1 of 2)
750GX Bus
Master Transaction
Transaction Source TT0 TT1 TT2 TT3 TT4
60x Bus Specification
Command
Transaction
Address only
1
Data Cache Block Store
(dcbst)
00000Clean block Address only
Address only
1
Data Cache Block Flush
(dcbf)
00100Flush block Address only
Address only
1
Synchronize (sync) 01000sync Address only
Address only
Data Cache Block Set
to Zero (dcbz)
01100Kill block Address only
Address only
1
Data Cache Block Inval-
idate (dcbi)
01100Kill block Address only
Address only
1
Enforce In-Order Exe-
cution of I/O (eieio)
10000eieio Address only
Single-beat write
(nonGBL
)
External Control Out
Word Indexed (ecowx)
10100External control word writeSingle-beat write
N/A N/A 11000
Translation Lookaside Buffer
(TLB) invalidate
Address only
Single-beat read
(nonGBL
)
External Control In
Word Indexed (eciwx)
11100External control word readSingle-beat read
1. Address-only transaction occurs if enabled by setting the HID0[ABE] bit to 1.
