IBM PowerPC 750GX User Manual

User’s Manual
IBM PowerPC 750GX and 750GL RISC Microprocessor
gx_08.fm.(1.2)
March 27, 2006
Bus Interface Operation
Page 299 of 377
Misaligned data transfers when the 750GX is configured with a 32-bit data bus operate in the same way as
when configured with a 64-bit data bus, with the exception that only the DH[0–31] data bus is used. See
Table 8-7 on page 299 for an example of a 4-byte misaligned transfer starting at each possible byte address
within a double word.
Half word
0 1 0 000 AA——xxxx
0 1 0 010 ——AAxxxx
0 1 0 100 AA——xxxx
0 1 0 110 ——AAxxxx
Word
1 0 0 000 AAAAxxxx
1 0 0 100 AAAAxxxx
Double word
Second beat
0 0 0 000 AAAAxxxx
0 0 0 000 AAAAxxxx
Note:
A: Byte lane used
—: Byte lane not used
x: Byte lane not used in 32-bit bus mode
Table 8-7. Misaligned 32-Bit Data-Bus Transfer (4-Byte Examples)
Transfer Size
(Four Bytes)
TSIZ[0–2] A[29–31]
Data-Bus Byte Lanes
01234567
Aligned 1 0 0 0 0 0 A A A A x x x x
Misaligned—first access 0 1 1 0 0 1 A A A x x x x
second access 0 0 1 1 0 0 A — — — x x x x
Misaligned—first access 0 1 0 0 1 0 — — A A x x x x
second access 0 1 0 1 0 0 A A — x x x x x
Misaligned—first access 0 0 1 0 1 1 — — — A x x x x
second access 0 1 1 1 0 0 A A A — x x x x
Aligned 1 0 0 1 0 0 A A A A x x x x
Misaligned—first access 0 1 1 1 0 1 — A A A x x x x
second access 0 0 1 0 0 0 A — — — x x x x
Misaligned—first access 0 1 0 1 1 0 — — A A x x x x
second access 0 1 0 0 0 0 A A — — x x x x
Misaligned—first access 0 0 1 1 1 1 — — — A x x x x
second access 0 1 1 0 0 0 A A A — x x x x
Note:
A: Byte lane used
—: Byte lane not used
x: Byte lane not used in 32-bit bus mode
Table 8-6. Aligned Data Transfers (32-Bit Bus Mode) (Page 2 of 2)
Transfer Size TSIZ0 TSIZ1 TSIZ2 A[29–31]
Data-Bus Byte Lanes
01234567
