Operator Panel Error Codes
Attention: If you replace FRUs or perform an action and the problem is still not corrected, go to “MAP
1540: Minimum Configuration” on page 110 unless otherwise indicated in the tables.
If you replace FRUs and the problem is corrected, go to ″MAP 0410: Repair Checkout″ in RS/6000 and
Eserver pSeries Diagnostic Information for Multiple Bus Systems.
Note: Do not shut down the system if the FRU was replaced by hot swap.
Table 4. Operator Panel Error Codes
Error Code Description Action/
Possible Failing FRU
0000 1111 At power on, failure of power-good signal
from power supply
1. Primary I/O backplane
Location: U0.1-P1
2. Primary I/O power supply
Locations: U0.1-V1
U0.1-V2
0000 1112 At power off, failure of power-good signal
from power supply
1. Primary I/O backplane
Location: U0.1-P1
2. Primary I/O power supply
Locations: U0.1-V1
U0.1-V2
0000 1113 While power on, failure of power-good signal
from power supply
1. Primary I/O backplane
Location: U0.1-P1
2. Primary I/O power supply
Locations: U0.1-V1
U0.1-V2
0000 1114 Primary I/O drawer operator panel and
service processor have been reset after main
power disturbance
Information message
0000 2222 Primary I/O drawer operator panel not
communicating with service processor
1. If system cannot be powered off, reset
the service processor (by the pinhole
reset or by disconnecting then
reconnecting power).
2. Primary I/O drawer backplane
Location: U0.1-P1
0000 3333 SPCN communications error Primary I/O backplane
Location: U0.1-P1
0000 3334 I2C repeater error Primary I/O backplane
Location: UO.1-P1
0000 BBBB TOD battery malfunction TOD battery
Location: U0.1-P1-V3
164 Service Guide
