CD-ROM Drive
Attention: Do not open the drive; no user adjustments or serviceable parts are inside.
CAUTION:
A class 1 laser is contained in the device. Do not attempt to operate the drive while it is
disassembled. Do not attempt to open the covers of the drive as it is not serviceable and is
replaced as a unit.
C07
Removal
1. Turn off power as described in “Powering Off the System” on page 415.
2. If you have not already done so, open the front door of the rack unit.
3. Loosen the two thumbscrews that attach the front bezel to the I/O drawer.
4. Grasp both sides of the front bezel and pull it off the drawer.
5. Push the release latch to the left and pull out the CD-ROM.
Release Lever
R
6. Disconnect the cables from the CD-ROM.
Chapter 10. Removal and Replacement Procedures 457
