Specifications
This section contains specifications for the system. Individual sections are provided for CEC drawer, rack,
and I/O drawer specifications.
CEC Drawer
The mechanical packaging, cooling, power supply, and environmental requirements for the CEC drawer
are shown in the following table:
Dimensions
Height
Width
Depth
355.6 mm
445.5 mm
825.5 mm
14.0 in.
17.5 in.
32.5 in.
Weight
Minimum
Maximum
69.7 kg
74.6 kg
158 lbs.
169 lbs.
Electrical
Power source loading typical in kVA
Power source loading maximum in kVA
Voltage range (V ac)
Frequency (hertz)
Thermal output (typical)
Thermal output (maximum)
Power requirements (typical)
Power requirements (maximum)
Power factor
Inrush current
Maximum altitude
0.39
0.6
200 to 240
50 or 60
M80: 1265 Btu/hr
6M1: 772 Btu/hr
M80: 1877 Btu/hr
6M1: 1378 Btu/hr
M80: 370 watts
6M1: 226 watts
M80: 550 watts
6M1: 406 watts
0.95
34 amps
2135 m (7000 ft.)
Temperature Requirements Operating
10 to 40°C
(50 to 104°F)
Non-Operating (Power Off)
10 to 52°C
(50 to 125°F)
Humidity (Noncondensing)
Without tape drive
With tape drive
Wet Bulb Requirements
Without tape drive
With tape drive
Operating
8 to 80%
20 to 80%
27°C (80°F)
27°C (80°F)
Non-Operating (Power Off)
8 to 80%
8 to 80%
27°C (80°F)
27°C (80°F)
Noise Emissions
1,2
With M80 CEC drawer only
L
WAd
L
pAm
<L
pA
>
m
Impulsive or prominent
discrete tones
Operating
6.4 bels
N/A
48 dBA
No
Idle
6.4 bels
N/A
48 dBA
No
Noise Emissions
1,2
With M80 and Primary I/O Drawer
L
WAd
L
pAm
<L
pA
>
m
Impulsive or prominent
discrete tones
Operating
6.5 bels
N/A
49 dBA
No
Idle
6.5 bels
N/A
49 dBA
No
Chapter 1. Reference Information 59
