Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service (See service clearances for the 7014 Series Model T00 Rack)
1. See “Noise Emission Notes” on page 63 for definitions of noise emissions positions.
2. Noise emissions data are based on the following configuration: the drawer is mounted in a 7014 Series Model
T00 Rack, a power distribution unit is installed in the rack, and the system is operating in a normal environment
of 25 °C (78 °F).
3. Inrush currents occur only at initial application of power; no inrush occurs during normal power off-on cycle.
7014 Series Model T00 Rack
The mechanical packaging, cooling, power supply, and environmental requirements for the rack are shown
in the following table:
Dimensions
Height
Width
Depth (including doors)
1804 mm
644 mm
1098 mm
71.0 in.
25.5 in.
43.3 in.
Weight
1
(Base Rack) 244 kg 535 lbs.
Electrical (see specifications for drawers or enclosures)
Temperature Range (see specifications for drawers or enclosures)
Humidity Requirements (see specifications for drawers or enclosures)
Noise Emissions (see specifications for drawers or enclosures)
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air
flow.
Service See “System Service Clearances” on page 62.
1. Configuration-dependent, base weight not including weight of drawers.
60 Service Guide
