I/O Drawer Specifications
Dimensions
Height
Width
Depth
218.0 mm 8.6 in.
445.0 mm 17.5 in.
820.0 mm 32.3 in.
Weight
Minimum configuration
Maximum configuration
41 kg 90 lbs.
52 kg 115 lbs.
Electrical
Power source loading (typical in kVA)
Power source loading (maximum in kVA)
Voltage range
Frequency (hertz)
Thermal output (typical)
Thermal output (maximum)
Power requirements (typical)
Power requirements (maximum)
Power factor
Inrush current
Maximum altitude
0.23
0.54
200 to 240 V ac
50 / 60
750 Btu/hr
1750 Btu/hr
220 watts
515 watts
0.95
41 amps
2135 m (7000 ft.)
Temperature Requirements Operating
10 to 40°C
(50 to 104°F)
Non-Operating
10 to 52°C
(50 to 125.6°F)
Humidity (Noncondensing)
Without tape drive
With tape drive
Wet Bulb Requirements
Without tape drive
With tape drive
Operating
8 to 80%
20 to 80%
27°C (80°F)
23°C (73°F)
Non-Operating
8 to 80%
20 to 80%
27°C (80°F)
27°C (80°F)
Noise Emissions
1,2
L
WAd
L
pAm
<L
pA
>
m
Impulsive or prominent
discrete tones
Operating
5.8 bels
N/A
45 dBA
No
Idle
5.8 bels
N/A
45 dBA
No
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service (See “System Service Clearances” on page 62)
1. See “Noise Emission Notes” on page 63 for definitions of noise emissions positions.
2. Noise emissions data are based on the following configuration: the drawer is mounted in a 7014 Series Model
T00 Rack and a power distribution unit is installed in the rack.
3. Inrush currents occur only at initial application of power; no inrush occurs during normal power off-on cycle.
Chapter 1. Reference Information 61
