Table 5. SPCN Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
1021 8A00 A different I/O drawer is connected to the
CEC
Informational only
1021 9012 Invalid address 1. Check SPCN cabling
2. Secondary I/O backplane
Location: U0.2-P1
1021 9013 Invalid address 1. Check SPCN cabling
2. Secondary I/O backplane
Location: U0.2-P1
1021 9014 Invalid address mode Update system firmware
Location: U0.1-P1/Y1
Note: Allow up to 30 minutes for this update
to take effect.
1021 9021 SPCN temporary internal error Information only
1021 9022 Secondary I/O drawer not present Check cabling
1021 9023 Secondary I/O drawer is present but off Information only
1021 902D Secondary I/O drawer not present Information only
1021 9038 I/O drawer node fault Secondary I/O backplane
Location: U0.2-P1
1021 9039 I/O drawer node fault Secondary I/O backplane
Location: U0.2-P1
1021 9042 EEPROM failure Secondary I/O backplane
Location: U0.2-P1
1021 9043 Download failure 1. Check for system firmware update
2. Call second level of support
1021 9046 QDS packet sequence error 1. Check for system firmware update
2. Call second level of support
1021 9047 QDS block sequence error 1. Check for system firmware update
2. Call second level of support
1021 9080 Undefined status code received Secondary I/O backplane
Location: U0.2-P1
1021 90F0 Drawer not present in configuration table 1. Check SPCN cabling
2. Reset system and reboot
3. Secondary I/O backplane
Location: U0.2-P1
1021 90F1 Drawer added to configuration table Information only
1021 9102 Permanent address assignment failed Secondary I/O backplane
Location: U0.2-P1
1021 9109 Download failure Secondary I/O backplane
Location: U0.2-P1
1021 9113 Firmware image corrupted Secondary I/O backplane
Location: U0.2-P1
1021 9114 Firmware image corrupted Secondary I/O backplane
Location: U0.2-P1
1021 9116 SPCN communication with operator panel
failure
1. Secondary I/O drawer operator panel
Location: U0.2-L1
2. Secondary I/O backplane
Location: U0.2-P1
180 Service Guide
