Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
460F 281D I/O system and error code generation/logging
detected Model 6M1 CEC backplane fault
CEC backplane
Location: U1.1-P1
460F 285D I/O system and error code generation/logging
detected SPCN fan controller fault
1. SPCN fan controller
Location: U0.1-X2
2. I/O drawer power distribution board
Location: U0.1-X1
460F 288A I/O system and error code generation/logging
detected memory riser card fault
1. Go to the service processor Memory
Configuration/Deconfiguration Menu to
verify memory DIMMs state. See
″Memory Configuration/Deconfiguration
Menu″ on page 374 for more information.
2. Memory riser card
Locations: U1.1-P1-M1
U1.1-P1-M2
460F 300A I/O system and error code generation/logging
detected 32 MB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
460F 300B I/O system and error code generation/logging
detected 128 MB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
460F 300C I/O system and error code generation/logging
detected 256 MB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
460F 300D I/O system and error code generation/logging
detected 512 MB (stacked) DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
460F 300E I/O system and error code generation/logging
detected 512 MB (unstacked) DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
460F 301F I/O system and error code generation/logging
detected 128 MB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
460F 303A I/O system and error code generation/logging
detected 1 GB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
460F 515B I/O system and error code generation/logging
detected 1100W ac power supply fault
1100W ac power supply
Locations: U1.1-V1
U1.1-V2
460F 51AC I/O system and error code generation/logging
detected 595W ac power supply fault
595W ac power supply
Locations: U0.1-V1
U0.1-V2
460F 51AD I/O system and error code generation/logging
detected 595W dc power supply fault
595W dc power supply
Locations: U0.1-V1
U0.1-V2
460F 51AE I/O system and error code generation/logging
detected 1100W dc power supply fault
1100W dc power supply
Locations: U1.1-V1
U1.1-V2
4B26 245B Processor system and scan interface basic
assurance tests detected 2W 4M processor
fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
Chapter 5. Error Code to FRU Index 315
