v Power Control Network Utilities Menu
This menu allows the user to do a lamp test on the operator panels and display, or change the I/O type.
POWER CONTROL NETWORK UTILITIES MENU
1. Lamp Test for all Operator Panels
2. Display I/O Type
3. Change I/O Type
98. Return to Previous Menu
1>
– Lamp Test for all Operator Panels
Selecting this option tests the operator panel indicators as follows:
Operator Panel Location Lamp Test Results
Primary I/O drawer Indicators blink on and off for approximately 30 seconds.
Secondary I/O drawers Indicators come on and stay on for approximately 30 seconds.
– Display I/O Type
I/O type and other data displays (blinks in one-second intervals) on all secondary I/O drawer
operator panels. All secondary I/O types are 84. Nothing displays on the primary I/O drawer operator
panel. After 20-30 seconds, the Power Control Network Utilities Menu redisplays on the console.
– Change I/O Type
Use this option to change the I/O type of the primary I/O drawer after a service action or
configuration change if the I/O type is incorrect. If this option is chosen, you are asked to make the
following entries.
1. For the I/O drawer address (drawer number), type:
- 1 for primary I/O drawer.
- n for secondary I/O drawers (n = 2, 3, 4).
2. For the I/O type, type:
- 87 for primary I/O drawer.
- 84 for all secondary I/O drawers.
If
you enter an invalid value, a failure message displays on the console. The Power Control Network
Utilities Menu is then redisplayed on the console.
378 Service Guide
