Index Part Number Units Per

Assy

Description

1 90H6641 1 SPCN bracket

2 24L0888 1 Busbar, power distribution unit

3 1621817 5 Busbar screws

4 97H7471 1 Power harness

5 1621811 4 Fan-mounting screw

6 90H6284 1 Shoulder screw power harness

7 24L0883 1 Fan-mounting assembly

8 44L0026 1 LED board assembly

9 1621811 4 Fan-mounting screw

10 04N3345 2 Digital fan assembly

11 44H8681 4 Fan-mounting screw

12 24L0775 1 Front EMC shield

13 44H8681 3 Front EMC screw

14 21H7141 1 Security label

Chapter 11. Parts Information 475
