Index Part Number Units Per Assy Description
1 03N3040 1 Misc. power cable (PDB to PCI board)
2 41L5517 1 Operator Panel Cable (I/O board to I/P)
3 41L5518 1 Base SPCN Cable (I/O board to I/P)
4 41L5516 1 Diskette Cable (I/O board to I/P)
5 41L5946 1 JTAG Cable (I/O board to bulkhead)
6 41L5521 1 V/S COMM Cable (I/O board to bulkhead)
7 41L5519 1 Internal SCSI (I/O board to I/P)
8 41L5649 1 Operator Panel Cable (I/P to Op panel)
9 42L5652 1 Fan Cont. Card Cable (PDB to FCC)
10 41L5650 1 Base SPCN Cable (I/P to PDB)
11 41L5522 1 Diskette Cable (I/P to diskette)
12 11K0233 1 Internal SCSI Cable (signal and power)
13 00P1676 1 Internal SCSI Cable (Int. to IPL DASD)
09P1709 1 Internal/external SCSI Cable (Ext. SCSI adapter to IPL
DASD)
14 09P1449 1 DASD power cable (PDB to IPL DASD)
15 34G0240 Up to 2 ac power cable
00P1799 Up to 2 dc power cable
16 88G3977 1 SCSI Terminator
482 Service Guide
