FRU Name
Location
Code
AIX
Location
Code
Physical
Connection
Logical
Connection
PCI slot 14 content (card) U0.2-P1/I14 7D-08 through
7D-0F
or 7E-xx or 7F-xx
PCI bus controller 1 U0.2-P1 00-FFF7E09000
PCI bus controller 2 U0.2-P1 00-FFF7E0A000
SPCN controller U0.2-P1
External SCSI connector U0.2-P1/Z1
Secondary I/O drawer
VPD module
U0.2-L1-N1
Thermal sensor (ambient) U0.2-L1
Thermal sensor (left) U0.2-P1
Thermal sensor (right) U0.2-P1
Power distribution board U0.2-X1
PDB power connector 1 U0.2-X1/V1
PDB power connector 2 U0.2-X1/V2
Fan Controller Card U0.2-X2 I/O board connector
J3
Power Supply 1 (w/Fan 5) U0.2-V1 PDB connector J2
Power Supply 2 (w/Fan 6) U0.2-V2 PDB connector J1
Fan 1 U0.2-F1 Fan connector P3 on
power supply 1
Fan 2 U0.2-F2 Fan connector P3 on
power supply 1
Fan 3 U0.2-F3 Fan connector P3 on
power supply 2
Fan 4 U0.2-F4 Fan connector P3 on
power supply 2
Cooling unit (w/fan 9) U0.2-F9 In cooling unit
SPCN firmware U0.2-P1/Y3
SPCN VPD U0.2-P1/Y4
Secondary I/O Drawer 3 Locations
Secondary I/O Drawer U0.3
RIO Bus Adapter U0.3-P1.1
RIO Port 0 Connector U0.3-P1.1/Q1
RIO Port 1 Connector U0.3-P1.1/Q2
All RIO Port Connectors U0.3-P1.1
Secondary I/O drawer
backplane
U0.3-P1
PCI to PCI bridge 1 U0.3-P1 90-58, 90-5A, 90-5C,
90-5E
PCI slot 1 U0.3-P1/I1 90-58
PCI slot 1 content (card) U0.3-P1-I1 91-08 through 91-0F
or 92-xx or 93-xx
40 Service Guide
