v Follow the suggested actions in the order in which they are listed in the Action column until the problem
is solved.
v See Chapter 3, “Parts listing, System x3500 Type 7977,” on page 41 to determine which components are
customer replaceable units (CRU) and which components are field replaceable units (FRU).
v If an action step is preceded by “(Trained service technician only),” that step must be performed only by a
trained service technician.
Power-supply
LEDs
Operator
information
panel
power-on
LED Description ActionAC DC
Off Off Off No power to the
server, or a problem
with the ac power
source.
1. Check the ac power to the server.
2. Make sure that the power cord is connected to a
functioning power source.
3. Remove one power supply at a time.
Lit Off Off DC source or power
supply power
problem.
1. Make sure that the system board is connected to the
power backplane.
2. Remove and replace one power supply at a time.
3. View the system-error log (see “Error logs” on page
100).
Lit Lit Off Standby power
problem.
1. View the system-error log (see “Error logs” on page
100).
2. Remove one power supply at a time.
3. (Trained service technician only) Replace the power
backplane.
Lit Lit Flashing System power-on
problem.
1. View the system-error log (see “Error logs” on page
100).
2. Press the power-control button on the operator
information panel.
3. Remove the optional Remote Supervisor Adapter II
SlimLine, and try to turn on the server.
4. (Trained service technician only) Replace the system
board.
Lit Lit Lit The power is good. No action is necessary.
Diagnostic programs, messages, and error codes
The diagnostic programs are the primary method of testing the major components
of the server. As you run the diagnostic programs, text messages and error codes
are displayed on the screen and are saved in the test log. A diagnostic text
message or error code indicates that a problem has been detected; to determine
what action you should take as a result of a message or error code, see the table in
“Diagnostic error codes” on page 140.
Running the diagnostic programs
To run the diagnostic programs, complete the following steps:
1. If the server is running, turn off the server and all attached devices.
2. Turn on all attached devices; then, turn on the server.
3. When the prompt F1 for Configuration/Setup is displayed, press F1.
