Notes:
1. Step .4/ is a DSP-model-unique step. DSP models
are:
 Models 760C/760E/760CD/760ED/760XD
2. In step .5/, gently push the levers to avoid flexing
them.
Step Size (Quantity) Torque
.7/ 6mm, Nylon (2) 4 kgcm
.8/ 8mm, Nylon (4) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
ThinkPad 760 (9546, 9547) 263
