4. Click Open in the left or right magazine column within the module that contains the magazine to be
opened.
5. A message box indicates when the magazine is unlocked.
6. Unlock Magazine screen shows that the magazine is now unlocked.
Note: If not removed, the magazine and the I/O station relock after 30 seconds.
To manually eject the magazine, insert a paper clip or a small flat head screwdriver into the appropriate
magazine release hole and gently push the tab in. See Figure 84 on page 148 and Figure 85 on page 148.
1. Open the magazine access door.
2. Insert a paper clip or a small flat head screwdriver into the appropriate magazine release hole and
gently push the tab in.
Figure 84. Manually releasing the right magazine
Figure 85. Manually releasing the left magazine
3. Pull the magazines out of the module.
Moving the library modules
When a library module is moved within the rack, to a different rack, or in a rack to a different physical
location, care must be taken to avoid personal injury and damage to the module.
148
IBM TS4300 Tape Library Machine Type 3555: User's Guide
