Figure 32. Unlocking the spring loaded lock

d. Lower the cover front end by about 10 cm ( 1 ) and pull gently forward ( 2 ) to disengage from the

pivot point at the unit center.

Figure 33. Removing the cover

2. Install the library bottom cover plate to an Expansion Module.

a. Place the Expansion Module on a work table.

b. Lift the unit front end by about 16 cm (use unit rear as a pivot edge).

c. Insert the bottom cover at the center

d. Lift the cover front edge until hard stop and it locks in at the unit front. The bottom cover ts only

one way.

IBM TS4300 Tape Library Machine Type 3555: User's Guide
