Statement 17:
CAUTION:
The following label indicates moving parts nearby.
4. Remove the power supply and power-supply filler from the server by pressing
down on the release latch while you pull out on the plastic handle.
Note: The power supply, power-supply filler, or power supplies must be
removed before you attempt to rotate the power-supply cage out of the way.
Power-supply
cage assembly
Power-supply
cage handle
5. Lift the power-supply cage handle on the rear of the power supply cage, and
rotate the power-supply cage out of the way until it latches in place. Let the
power-supply cage rest on the rear power-supply structure support bracket.
Attention: To avoid breaking the retaining clips or damaging the DIMM
connectors, open and close the clips gently.
6. Install the DIMMs into DIMM connectors:
Chapter 2. Installing optional devices 17
