Pb Battery Charge Safety Setup
Click " " to enter CHARGE SAFETY SETUP interface, see details about setting on Page19 LiPo/LiIo/LiFe Battery
Charge Safety Setup.
Pb Battery Discharge Setup
Select Program→Discharge to enter Discharge setup interface, see details about setting on Page20 LiPo/LiIo/LiFe
Battery Discharge Setup.
Pb Battery Cycle Setup
Select Program→Cycle to enter Cycle setup interface, see details about setting on Page21 LiPo/LiIo/LiFe Battery Cycle
Setup.
NiZn Battery Charge/Discharge Setup
After adding a program, it will switch to NiZn battery in Type option on the MEMORY SETUP interface. Set the capacity,
the number of cells for NiZn battery cannot be set, and the charger sets Auto by default, after editing all parameters for
the program, click" " to save and return to the previous interface.
As shown in above picture, the program of NiZn has the following modes: Charge, Discharge and Cycle.
NiZn Battery Charge Setup
Select Program→Charge to enter Charge setup interface.
Note: When the battery cell charging voltage setting exceeds the recommended value (1.9V), there will be a
warning display and alarm voice. As long as the user changes the value, the battery type and cell voltage
values on the main interface of charger will display alternately.
NiZn Battery Not Balance Charger Setup
Switch to Not Balance mode on Chg Mode interface, see details about setting on Page17 LiPo/LiIo/LiFe Battery Not
Balance Charge Setup.
NiZn Battery Balance Charge Setup
Switch to Slow Balance
，
Normal Balance
，
Fast Balance
，
User Balance on Chg Mode interface, see details about setting
on Page17 LiPo/LiIo/LiFe Battery Balance Charge Setup.
Chg Current: 0.05A-30A; default: 2A
Chg Mode: Slow Balance, Fast Balance,
Normal Balance, User Balance,
Not Balance( default)
Chg End Current
1%-50%; default:10%
Chg Cell Volt
1.2V/Cell-2V/Cel; default: 1.9V/Cell
