Appendix
 Status Indication of Running Channel
Status
Status Indication
Status
Status indication
No display
No program, can select program to run
TRICK
Trickle charging status keeps a small
current for a while after finishing
charging NiCd or NiMH
STOPS
Stop status, press “stop” button to stop
the running program
MONITO
Monitor status, only monitors the data
START
Start the program
FLOAT
Float charge, supports Pb battery
CHECK
Check status before running program
SYNCH.
Synchronous status, this channel runs
with another channel synchronously
CHARGE
Charge status
LOAD
Load status, this channel works on the
load control status of Channel
regenerative
DISCHG
Discharge status
WAIT
Waiting status
PRE_C
Pre-charge, program will pre-charge
when the cell voltage is too low
CY_DE
Cycle delay status
KEEP
Keep charging status, keep charging for
a while after setting pre-charge
OVER!
Over status
BAL
Independent balance status. Only for
balancing, not charging the Li-battery,
ERROR
Error status
 Status Indication of Channel Control
Status
Status Indication
Status
Status Indication
O.CV
Constant voltage status of output
voltage
I.CC
Constant current status of input
current
B.CV
Constant voltage status of Li-battery
cells voltage
I.CP
Constant status of input power
O.CC
Constant current status of output
current
O.C0
0 current regulation status
C.CP
Constant status of output power
capacity
O.CP
Total power regulation status
C.TP
Temperature power reduce status
C.BL
Channel imbalance regulation status
I.CV
Constant status of input voltage
O.PC
Channel power containment
regulation status
