NiZn Battery Charge Advanced Setup
Click " " to enter NIZN ADVANCED SETUP interface, see details about setting on Page19 LiPo/LiIo/LiFe
Battery Charge Advanced Setup.
NiZn Battery Charge Safety Setup
Click " " to enter CHARGE SAFETY SETUP interface, see details about setting on Page19 LiPo/LiIo/LiFe Battery
Charge Safety Setup
NiZn Battery Discharge Setup
Select Program→Discharge to enter Discharge setup interface
Note: 1.The charger first discharges with constant current (CC) according to the user setting then turns
to constant voltage (CV) when it reaches the discharge voltage. In the CV phase the current
gradually falls, and the charger will terminate discharging when the current falls below the
percentage of the configured discharge current.
2. Regenerative mode has three available settings: OFF, To input, To channel, see more details on
Page37 Important Notes
To Channel Setup
Switch to To channel mode on Regenerative Mode interface, click“ ”to enter To channel setup interface, see
details about setting on Page20 To Channel Setup.
NiZn Battery Discharge Advanced Setup
Click “ ” to enter NiZn DISCHARGE ADVANCED SETUP interface, see details about setting on Page20
LiPo/LiIo/LiFe Battery Discharge Advanced Setup.
NiZn Battery Discharge Safety Setup
Click“ ”to enter DISCHARGE SAFETY SETUP interface, see details about setting on Page19 LiPo/LiIo/LiFe
Battery Charge Safety Setup.
NiZn Battery Cycle Setup
Select Program→ Cycle to enter Cycle setup interface, see details about setting on Page21 LiPo/LiIo/LiFe Battery Cycle
Setup.
Discharge Current: 0.05A-30A
；
default: 2A
Discharge Voltage: 0.9V/Cell-1.6V/Cell;
default: 1.1V/Cell
End Current: 1%-100%; default: 50%
Regenerative Mode:
OFF(default),To input, To channel
