iCharger 4010DUO - Page 41

iCharger Synchronous Balance Charger/Discharger 4010DUO
- 41 -
28XX
"Number of cells setting appears high"
Number of cells setting appears high
29XX
"Balance not needed, Remove connection from balance
port"
Balance port error, Ni-, Pb does not
need balance port, but voltage of
balance port is detected
30XX
"Balance required!"
Balance port is unplugged
31XX
"Auto detect the number of cells failed, please connect
balance or set cells"
Check connection or balance port
32XX
"AD watchdog error"
AD watchdog error
33XX
"Synchronous mode: Channel outputs imbalance"
Channel outputs are imbalance in
Synchronous mode
34XX
"This channel is needed to access the resistor or bulb
load"
This regenerative channel is needed
to access the resistor or bulb load
35XX
"The other channel is occupied"
The other channel is occupied
