iCharger Synchronous Balance Charger/Discharger 4010DUO
- 7 -
STATUS-1
Long press: measure internal resistance of CH-1 via long press on
initial interface, and to pop up the parameters setup
interface via long press when running program
Click: switch to the information display of CH-1 when running
program
STATUS-2
Long press: measure internal resistance of CH-2 via long press on
the initial interface, and to pop up the parameters
setup interface via long press when running program
Click: switch to the information display of CH-2 when running
program
STOP/START-1
Click: click on the initial interface to enter CH-1-BATTERY
MEMORY SELECTION, and click again to return the
initial interface
Long press: long press on the initial interface to enter the last
running program of Run Program on CH-1, and long
press again to run the selected program
STOP/START-2
Click: click on the initial interface to enter CH-2-BATTERY
MEMORY SELECTION, and click again to return the
initial interface
Long press: long press on the initial interface to enter the last
running program of Run Program on CH-2, and long
press again to run the selected program
STATUS-1+STOP/START -1
Press simultaneously on initial interface to enter CH-1-MONITOR
SETTINGS on CH-1
STATUS-2+STOP/START -2
Press simultaneously on initial interface to enter CH-2-MONITOR
SETTINGS on CH-2
STOP/START -1+STOP/START -2
Long press simultaneously on Run Program interface, two
channels will run the same program simultaneously
Fan status: a. Grey shows not running
b. Green shows running (the higher the green shows,
the faster the fan runs, and vice versa)
SD card status: a. Grey shows the SD card is not inserted
b. Green shows the SD card has been inserted and
can be used normally
USB status: a. Grey for no USB connection
b. Green for USB connection
