ICM Controls I3 1010HR - Configuration Settings: Fan and Humidity Control; Hourly Cycle Fan Operation; Humidification;Dehumidification Setup; Humidity Differential Setting

16
CONFIG
HUMIDITY
%RH
19.HumidityDifferential(1%to10%)
Setthepercentdifferencebetweenthesetpointhumidityandwhenthehumidierordehumidier
systemturnson.
Pressthe or toselect.Press toadvancetothenextscreen.
CONFIG
HUMIDITY
20.ConditiontoTurnOn
Settheconditionforsystemtofollow:
Humidication
No=Noconditionotherthanhumidityreading
belowsetpointanddifferentialwillturnonthe
humidier.
HEAT=Heatmustbeenergizedinorderfor
thehumidiertoturnon.
HEAT-FAN:Eithertheheatorthefanmustbe
energizedinorderforthehumidiertoturnon.
Dehumidication
No=Noconditionotherthanhumidityreading
abovesetpointanddifferentialwillturn
onthedehumidier.
COOL-FAN=Eitherthecoolingsystemorthefan
mustbeenergizedinorderforthedehumidier
toturnon.
COOL-no=Coolingsystemcannotbeenergizedin
orderforthedehumidiertoturnon.
Pressthe
or toselect.Press toadvancetothenextscreen.
17.HourlyCycleFanOperation(1-30 minutes per hour)
UsedinconjunctionwiththeFanHOURLYmode.Whentheuserselectsthisoption,thefanwill
turnonatthebeginningofeveryhourandrunforthenumberofminutesindicatedhere.
Pressthe
or toselect.Press toadvancetothenextscreen.
CONFIG
HOURLY
CONFIG
HUMIDITY
18.Humidication/Dehumidication (Hu, dE)
Setsystemcongurationtoworkwithahumidierordehumidier(includingairconditioner).
Note:Incorrect settings can damage system and/or cause potentially dangerous conditions.
UsethecodedescribedinCongurationSafetyLocktoaccessthisscreensetting.
Hu:usedwithahumidiertohumidifyhome.
dE:usedwithairconditionerordehumidiertodehumidifyhome.
Pressthe
or toselect.Press toadvancetothenextscreen.
