Icom IC-M25 User Manual

2
ACCESSORIES ATTACHMENTS
2
Supplied accessories
Attachments
Antenna ❏
Connect the supplied antenna to the antenna connector.
CAUTION:
•NEVER carry the transceiver
by holding just the antenna.
•Transmittingwithoutan
antenna can damage the
transceiver.
Handstrap ❏
Pass the handstrap through
the loop on the back side of
the transceiver to make it
easy to carry.
Belt clip ❏
Attach or detach the belt clip.
Handstrap
Belt clip
Antenna
(5 V/1 A)
Power adapter*
*Not supplied, or the shape is different, depending
on the transceiver version.
To attach the belt clip
To detach the belt clip
Be careful!
Don’t break your
fingernail.
q
Belt clip
w
Lift the tab up (q), and slide
the belt clip in the direction
of the arrow (w).

Icom IC-M25 Specifications

General

Battery type	BP-282
Battery life (max)	11 h
Battery low indication	Yes
Number of batteries supported	1
Purpose	Marine Radio Service
Operating frequency	156.025 - 157.425 MHz
Display type	LCD
USB connector type	Micro-USB B
Antenna connector type	FA-SC59V
Product color	Black, White
Waterproof up to	1 m
International Protection (IP) code	IPX7
Operating temperature (T-T)	-20 - 60 °C
Number of batteries included	1 pc(s)

Weight and Dimensions

Depth	30.5 mm
Width	56.6 mm
Height	134.2 mm
Weight	220 g
